4-AXLE CONTAINER SEMI-TRAILER
SPECIFICATIONS
We are ready to consider the issue of manufacturing this equipment, according to the technical specifications of the Customer
PORTABLE CONTAINER SIZES
1x45’
1x40’
1x30’ centre Or 1x20’ centre
2x20’
1x40’
1x30’ centre Or 1x20’ centre
2x20’
AXLE SHAFT
4 axle shafts with the capacity of 12 tons
ELEVATING FRONT AXLE SHAFT
Remote operated elevating system for front axle shaft in cabin
ELECTRICAL EQUIPMENT
It is suitable for SAE standards and Tüv regulations
Electricity is provided by 7 pin plug from vehicle
There are necessary traffic advisory and stoplights on both sides
There are backlights, brake lights, license plate lamps, trailer reflectors and orange warning lights on the sides
Electricity is provided by 7 pin plug from vehicle
There are necessary traffic advisory and stoplights on both sides
There are backlights, brake lights, license plate lamps, trailer reflectors and orange warning lights on the sides
KING-PIN
2" DIN 74080 and 3.5" DIN 74083 in steel 42 CRM04. Brand – OMS
CONTAINER LOCK
12 or 14 locks
PAINT
Rack and superstructure are painted in paint drying oven by Washing + Sanding + 2+1 coat Acrylic Paint
STANDARD ACCESSORIES
Multi-piece plastic fenders that covers trailing axle tires
1 plate tool box
Control Panel(Mob, air clock, access ramp lever)
Plastic water tank
Roller spare tire conveyor
Aluminum bike impact absorber
Mounting and mounting space
1 plate tool box
Control Panel(Mob, air clock, access ramp lever)
Plastic water tank
Roller spare tire conveyor
Aluminum bike impact absorber
Mounting and mounting space
RACK
It is manufactured in 20’30’40’45’ FEET container sizes
Strengthened “I” section centre members are welded automatically by submerged welding machine
Spar 10 - 12 mm thick made of steel 10HSND or S700
Chassis 5 - 6 mm thick made of steel 10HSND or S700, transverse 6 mm thick units made of steel S700
These racks are supported by binding with axle beams against being twisted with each other.
Strengthened “I” section centre members are welded automatically by submerged welding machine
Spar 10 - 12 mm thick made of steel 10HSND or S700
Chassis 5 - 6 mm thick made of steel 10HSND or S700, transverse 6 mm thick units made of steel S700
These racks are supported by binding with axle beams against being twisted with each other.
SUSPENSION
- Pneumatic
- spring balancer
- spring balancer
TIRES AND RIMS
385/55 R22,5 tires 6+1
BRAKE EQUIPMENT
- Wabco ABS
- Wabco EBS
- Wabco EBS
LEGS
Two speed, telescopic, mechanical conveyor legs, with the capacity of 24 tons
FLOOR
-
COLOR
It will be specified according to customer request
OPTIONAL SPECIFICATIONS
European axle shaft group and all kind of equipments
Aluminum rims
Fire extinguisher closet and fire extinguisher tube
Tire mark according to request
RAL color codes according to request
Chassis steel Strenx 700
Aluminum rims
Fire extinguisher closet and fire extinguisher tube
Tire mark according to request
RAL color codes according to request
Chassis steel Strenx 700
WE'LL HELP YOU TO CHOOSE THE RIGHT EQUIPMENT
We are ready to consider the issue of manufacturing any of our equipment in accordance with the requirements of the Customer.
Leave a request, our manager will contact you shortly.
FAQ
What are the benefits of a 4-axle container chassis in heavy container transport?
A 4-axle container chassis is designed for transporting extremely heavy containers while meeting strict axle-load regulations.
How does the fourth axle improve legal load compliance on long-haul routes?
The fourth axle helps distribute weight more evenly, allowing higher payloads without exceeding legal axle limits.
Can a 4-axle chassis trailer carry two containers simultaneously?
Yes, some models can carry two 20-ft containers or one 40-ft container, depending on locking positions and local road laws.
What types of suspension systems are used in 4-axle chassis trailers?
Air or mechanical suspensions are standard, with optional lift or self-steering axles to improve ride quality and reduce wear.
Are these trailers suitable for both port and inland logistics operations?
Absolutely, 4-axle chassis are used in both port drayage and long-distance inland transport, especially for heavy export loads.
How does axle configuration affect tire wear on container hauls?
More axles reduce the stress per wheel, improving tire life over time, especially under maximum container weights.
Is a 4-axle container chassis compatible with all ISO container sizes?
They typically support 20-ft, 40-ft, and 45-ft ISO containers using adjustable twist locks and sliding bogie systems.
What is the typical gross weight capacity of a 4-axle chassis trailer?
Depending on local regulations, gross weight can range from 50 to over 70 tons, particularly for steel-loaded or reefer containers.
Do 4-axle models support rear steering for enhanced maneuverability?
Yes, some trailers include self-steering or hydraulic steering axles to help with turning in confined spaces or terminals.
Are these trailers allowed in all countries for road transport?
Not all jurisdictions permit 4-axle trailers on standard roads, so route planning and transport permits are often required.
